  • Based on the suction dividing principle
  • Suitable for fresh dough with 60–85% hydration
  • Available with single or double piston configurations, depending on capacity requirements
  • Various piston sizes available for different dough weight ranges
  • Dual closed-loop lubrication system for optimum performance
  • Two oil reservoirs with filters for low oil consumption
  • External oil level inspection window
  • External oil filling port for easy refilling
  • Low oil level alarm and warning indicator
  • 70-liter hopper capacity
  • Weight accuracy of ±3%
  • Integrated flour duster unit
  • Variable speed control with inverter
  • Height-adjustable conveyor belt with belt-cleaning scraper
  • Heavy-duty 12 mm steel plate main frame
  • Stainless steel drum
  • Stainless steel exterior panels
  • Dough weight and motor tension adjustment via handwheels
  • Electromechanical control system
  • Heavy-duty caster wheels for easy mobility
  • Equipped with safety photocells
  • CE and EAC certified
  • 2-year warranty



Optional Features & Accessories

  • Teflon-coated hopper for sticky dough applications
  • Stainless steel hopper cover with safety photocell
  • Clock-style handwheels for dough weight and motor adjustment
  • Digital control panel (PCB-based model)
  • Digital dough piece counter and weight adjustment system
  • XL hopper with capacities up to 120 liters
  • Stainless steel or PVC conveyor belt options
  • Customized piston sizes for specific dough weight requirements
  • Special voltage and frequency configurations available upon request













MODELS & TECHNICAL SPECS.
Model - Modelo Unit KST 2000 Single Piston KST 2000 Double Piston
Capacity / Capacidad / Kapasite / Capacité / Capacità / Производительность / السعة Ad/pcs 2400 3600
Dough Range / Rango de Peso / Hamur Gramaj Aralığı / Plage de Poids / Range di peso / Диапазон веса теста / نطاق وزن العجين gram Piston Ø 70mm|30/250 gram
Piston Ø 80mm|40/350 gram
Piston Ø 90mm|70/450 gram
Piston Ø 100mm|80/500 gram
Piston Ø 110mm|100/600 gram
Piston Ø 130mm|200/1000 gram
oz/lb Piston Ø 2.75" | 1–9 oz
Piston Ø 3.15" | 1–12 oz
Piston Ø 3.55" | 2–16 oz
Piston Ø 3.95" | 3–18 oz
Piston Ø 4.35" | 4–21 oz
Piston Ø 5.15" | 7–35 oz
Width / Ancho / Genişlik / Largeur / Larghezza / Ширина / العرض (W) mm 700 900
(inch) 28 35
Length / Largo / Uzunluk (L) / Longueur / Lunghezza / Длина / الطول (L) mm 1450 1450
(inch) 57 57
Height / Altura / Yükseklik (H) / Hauteur / Altezza / Высота / الارتفاع (H) mm 1720 1720
(inch) 68 68
Power / Potencia / Güç / Puissance / Potenza / Мощность / القدرة V/hz 380V 50/60Hz (3Ph/N+PE)
Hopper capacity/Capacidad de la tolva
Hazne kapasitesi/Capacité de la trémie
Capacità della tramoggia/Ёмкость бункера
سعة القمع		 Liter 70 90
Voltage / Voltaje / Voltaj / Tension / Tensione / Напряжение / الجهد الكهربائي KW 1.1 1.5
Weight / Peso Neto / Ağırlık / Poids / Peso / Вес / الوزن KG 450 600
(lb) 992 1323
Material / Materyal / Matériau / Materiale / Материал / المادة - Stainless Steel / INOX/ Paslanmaz Çelik / Нержавеющая сталь / الفولاذ المقاوم للصدأ
