  • Direct Dough Lamination –Dough is formed between belt and rollers
  • Four Rear-Side Handle – Fine-tunes dough forming with precision
  • Universal Compatibility – Compatible with all ovens and equipment
  • Multiform – Ideal for all kind of bread in shaping
  • "Flexi Layer" Pressure Boards – Ondermak-designed for optimal dough shaping
  • 2 x Gran Pressure Boards – Front and back
  • Bolted Joint – Easy to replace  pressure boards
  • Non-Stick German Rollers – x 2 units
  • Board Selection  – Flat, curved, semi-curved boards
  • Featured - Flour duster unit
  • Dough Feeding – Independent conveyor dough feeding with  dough centralizer
  • Waste Management  - Flour recycle trays
  • Front Dough Collector Stand – Ensures smooth dough collection
  • Durable Construction – Entire structure and legs made of stainless steel
  • Heavy-Duty Casters – Easy mobility with locking brakes
  • Safety Features – Transparent hand protection panels on front
  • Analogue control – User friendly
  • Low Maintenance – Easy to clean and maintain.
  • CE Certified
  •  2-year warranty



Technical Specifications

Kapasite / Capacity / Capacidad

Adet/sa. - Pcs/hr.

4800 – 6000

 Şekil Verme Aralığı / Dough Range / Rango De Masa

 gr.

50-1200

Yastık Sayısı / Pressure Board Nr. / Nr. Tablero

 Nr.

2

 Genişlik (W) / Width / Ancho

  mm

975

 Uzunluk (L) / Length / Largo

  mm

2510 +430

Yükseklik (H) / Height / Alto

  mm

1050

Hamur Giriş Yüksekliği (H1) / Dough Input / Masa Entrada

 mm

1250

Hamur Çıkış Yüksekliği (H2) / Dough Output / Masa Salida

  mm

760

Elektrik Gücü / Electric Power / Energía

  Kw

   1.1

 Elektrik Bağlantı / Electric Connection / Conexión Electrica

 Volt-Vac/Hz

 380v/50-60hz 3 Phase

Ağırlık / Weigth / Peso

  Kg

300

Merdane Ayari / Roller Adjustment / Ajusto Rodillo

 mm

  0-25

 Ekmek Uzunluğu / Max. Form Length / Max. Largo Formacion

 mm

450

 Taşıma Bandı Genişliği / Conveyor Belt Width / Ancho Cinta

 mm

480

Taşıma Bandı Boyu / Conveyor Belt Length / Largo Cinta

 mm

4000

Unlama Ünitesi / Flour Duster / Harinadora

 -

 Var/Yes/Si

Materyal / Material

 Paslanmaz

 Stainless Stell/Inox

  Un Toplama Tepsisi/Flour Recyle Tray/Bandeja Harina Reciclo



 Var/Yes/Si
